The utility model relates to the technical field of the mesh belt, discloses a combined type chain mesh belt, comprising N-type mesh wire, the upper end of the N-type mesh wire is provided with an upper bending, the lower end of the N-type mesh wire is provided with a lower bending, the lower end of the N-type mesh wire is provided with a threading line, the threading line is provided with a convex section and a concave section, the convex section and the concave section are connected at the end, the upper bending and the concave section are hinged, the lower bending and the convex section are hinged. The lower end of the thread is provided with a chain rod, the chain rod is provided with a chain wheel on both sides, the chain rod runs through the chain wheel, the outside of the chain wheel is provided with an inner chain, the inside chain is provided with an outside chain, the outside chain is provided with an outside chain, the outside chain is also provided with a symmetric sprocket setting, the outside chain is provided with a fixed block, the fixed block is provided with a symmetric chain rod setting.

Compared with the prior art, the mesh belt has a single structure, low practicability, easy to snake, and affects the transportation operation.

The utility model has the advantages that the whole transmission efficiency of the device is high and the utility model has high practicability by articulating the N-type mesh wire and threading wire and fixing the chain rod.
