The utility model relates to the technical field of mesh belt processing equipment, specifically a drying device for mesh belt processing, including a drying device body, a conveying mechanism is provided in the inner cavity of the drying device body, a hot air conveying mechanism is provided above the conveying mechanism, an auxiliary net is connected below the hot air conveying mechanism, and a plurality of drying heating pipes are provided on the bottom surface of the auxiliary net; a moisture extraction mechanism is provided below the conveying mechanism, and a heat energy reflection net is connected to the top of the moisture extraction mechanism.
The utility model arranges a hot air conveying mechanism at the top of the inner cavity of the drying device body, and arranges a moisture extraction mechanism at the bottom of the inner cavity of the drying device body, so that the air flow in the inner cavity of the drying device body moves, and moisture is quickly discharged during the drying process; an auxiliary net is fixed at the bottom of the hot air conveying mechanism in the inner cavity of the drying device body, a drying heating pipe is installed at the bottom of the auxiliary net, and a heat energy reflection net is connected to the top of the moisture extraction mechanism, so that the heat energy of the drying heating pipe is repeatedly used, further improving the drying efficiency.
